/pub/cbm/schematics/cartridges/vic20/

Cartridges for the VIC-20

Subdirectories

ieee-488/
Commodore IEEE-488 cartridges, such as VIC-1112
userport@
Cartridges that plug in the user port

Files

vic20cvc.bin 1996-08-19 2048
Firmware of the Color Video Controller cartridge. Downloaded from http://www.republika.pl/jsobola/schematy.htm.
vic20cvc.gif 2001-01-26 33372
Reverse engineered schematic diagram of a Color Video Controller device (scrolling text interface) that plugs to the cartridge port and to the user port. Drawn by Jerzy Sobola, January 26, 2001. Downloaded from http://www.republika.pl/jsobola/schematy.htm.
